Mini Scorpio Head 2-Axis
Servicevision

Mini Scorpio Head 2-Axis

3 600 SEK
  • Rental Product
  • Insurance included
  • Worldwide Shipping
Add to cart
  • Compare this product
  • Add to Favourites
Product no. 1001972.00
Mini Scorpio Head 2-Axis image 1
Mini Scorpio Head 2-Axis image 2
Mini Scorpio Head 2-Axis image 3
Mini Scorpio Head 2-Axis image 4
Youtube video thumbnail
https://www.ljud-bildmedia.se/page/product/servicevision-scorpio-sb92-mini-head

Product Information

2 or 3-Axis remotehead with sliprings so you are able too rotate each axis how many turns you want without thinking of any cables getting stuck

.
HD SDI signal thru the sliprings

Third roll axis can be added separately.

Specifications

DepartmentGrip
CategoryRemote / Stabilized Heads
Product no.1001972.00
SKU / MPN
TypeRental
BrandServicevision
Head Weight18 kg
Max Payload 2-axis45 kg
Max Payload 3-axis20 kg
Max Speed2.5 sec for 360 deg
Power Reqiurment24V > 35V
Camerapower2 Out 12V / 12.5 A
1 Out 26.7V / 12.5 A
Slipring Throughput1 SDI, 1 HD-SDI

Shipping Dimensions

Width86 cm
Height70 cm
Depth43 cm
Weight52.50 kg

Included with Mini Scorpio Head 2-Axis

Included with Mini Scorpio Head 2-Axis

1xCartoni Tripod Set for Scorpio Systems
1xMonitor 17" for Remote Head
1xMulti Cable Set for Scorpio Systems
1xScorpio Power Unit 2x 3-Pin XLR 30V 20A Servicevision 1303
1xCartoni Tripod Set for Scorpio Systems
1xMonitor 17" for Remote Head
1xMulti Cable Set for Scorpio Systems
1xScorpio Power Unit 2x 3-Pin XLR 30V 20A Servicevision 1303
